A new generation of dry cleaning machines
01/04/2013
based on alternative solvents (hydrocarbon KVL and SILICONE D5):
KTR Series - the most compact "slim" configurations.
2 tanks, loading 10 - 15 kg.
There are three models available in the KT R series:
KT 210 – Loading weight of 10 kg
KT 212 – Loading weight of 12 kg
KT 215 – Loading weight of 15 kg.
KMR Series - traditional "wide" design.
2-3 tanks, loading 10-15 kg.
There are six models available in the KM R series:
KM 210 – Loading weight 10 kg, two-tank
KM 212 – Loading weight 12 kg, two-tank
KM 215 – Loading weight 15 kg, two-tank
KM 310 – Loading weight 10 kg, three-tank
KM 312 – Loading weight 12 kg, three-tank
KM 315 – Loading weight 15 kg, three-tank.
KT Series - "narrow" high-load machines.
2 tanks, loading 18-25 kg.
There are three models available in the KT series:
KT 343 – Loading weight 18 kg
KT 403 – Loading weight 20 kg
KT 503 – Loading weight of 25 kg.
KM Series - maximum performance and capabilities.
3 tanks, loading 18 - 40 kg.
There are five models available in the REALSTAR KM 03 series:
KM 343 – Loading weight 18 kg
KM 403 – Loading weight 20 kg
KM 503 – Loading weight of 25 kg
KM 703 – Loading weight 32 kg
KM 803 – Loading weight of 40 kg.
The highest technological efficiency of the new series of machines makes it possible to use Class III A solvents in them, which makes it possible to process any textile products in them without loss of their consumer properties and color gamut.
After cleaning and subsequent drying in the machine, textiles are saturated and pleasant to the touch, fully retain their natural softness and are practically odorless.
It is also important that the use of solvents of this class and cleaning programs developed by our specialists minimizes the wear of the fibers of materials and the formation of wrinkles on it. This significantly reduces the cost of labor and time in the subsequent stages of finishing.
Thanks to the verified analysis of the mutual arrangement of components and assemblies, these machines are also very easy to install, but especially easy to use. All controls and controls are easily visible and accessible and are located on the front panel.
The new series of machines can be installed so that its side panel (whether left or right) is flush against the wall, since it does not require any maintenance from the sides.
On the back side, all those components that require daily or periodic maintenance are easily visible and accessible, making it easier to work with the machine. The large loading hatch facilitates quick loading and unloading of items.
The new series of machines are equipped with two or three large-volume tanks with large-diameter inspection hatches.
PULSAR D601 and the COMBI System.
A computer based on Pulsar D601 microprocessors, equipped with a new generation Combi System, is used as the machine's control system. This system allows you to manage 20 cleaning and maintenance programs that are easy to call up and modify at any moment. If there are a lot of machines in the dry cleaning and they need to be synchronized, this can be done using a memory card (included), on which you can record programs and transfer them from one machine to another.
With the help of the COMBI System, for each cleaning program, you can easily and quickly set the temperature of the solvent and the drying air at the inlet and outlet of the drum, the speed of the cleaning motor, the dosage of chemicals –everything you need to achieve the perfect treatment quality. The PULSAR D601 computer equipped with the COMBI System is really a real breakthrough in the field of dry cleaning machine control!
An innovative first car wash!
Another important novelty is implemented in the KM series machines. We are talking about a new system for the reuse of solvent, which is formed during the first phase of distillation and mixed in a special separator with solvent, which is released during the drying process. The resulting mixture is used in the first wash, which ensures the highest cleaning quality with significant cost savings, since fewer consumables are required. The electronic probe constantly monitors the formation of water during the separation process and, upon detection of moisture, gives the command to automatically open the drain valve into the second water separator, preventing the formation of bacteria in the circuit.
Fractional distillation.
Distillation in dry cleaning machines running on hydrocarbon solvents is one of the most delicate operations. The KM 03 series machines are equipped with a FRACTIONAL DISTILLATION system. Thanks to the use of special electronic sensors, the solvent boiling process is automatically monitored, preventing the formation of foam that could clog the pure solvent and cause the formation of bacteria and, as a result, unpleasant odors in the machine. Using this innovative system allows you to work only with pure regenerated solvent at all times, which ensures optimal cleaning quality. Distillation is carried out using vacuum technology.
Optimal and reliable drying.
The innovative air circulation system, which includes a powerful ventilation circuit with large turbines in combination with a volumetric refrigeration unit, allows achieving results that were previously unattainable for hydrocarbon machines. The drying system is equipped with ELETTRONICO's electronic DRY CONTROL as standard, which allows perfectly dry and odorless products to be removed from the machine at the end of the cycle. This also provides significant solvent savings. Special attention was also paid to the periodic maintenance of the system. The KT-KM 03 series machines are equipped with a refrigeration unit consisting of THREE separable sections (an evaporator battery, a condensing battery and the refrigerator itself). Dismantling the installation if necessary to clean the batteries is easy and simple thanks to the use of quick coupling connectors “AEROQIUP".
STANDARD EQUIPMENT:
Safety tray
Locking signal and hatch lock
DANFOSS Water saving valve
Cleaning motor INVERTER
Self-cleaning Electronic Drying Control Dry Control
Double water separator for contact water
Automatic Detergent Dosing Pump
Fractional distillation by vacuum technology
Connector for connecting a nitrogen cylinder
Continuous or periodic distillation
A trap equipped with an automatic drying device
Self-cleaning water separator
The noise-absorbing casing of the refrigerator compressor
A microprocessor-based computer
Up to 20 cleaning programs
Choosing one of the 14 machine control languages
Electronic temperature control
Wide range of filtering options
Large loading hatch
Automatic wall washing of the distiller
Large size Double Air Filter
Electric Steam Distiller
Distiller with pressurized water
Illuminated distiller viewing window
Large-size ventilation turbine
Refrigeration unit with three separable sections for quick and convenient maintenance.
Stainless steel components:
The distiller
Distiller Condenser
The trap
Contact water separator
The second water separator
Solvent Filters
Drum
Air contour
Additional options:
Automatic sludge discharge from the distiller
Distiller Cleaning Scraper
Sludge collection can with a set of connecting elements
Built-in air compressor
POLAR SYSTEM – Solvent cooling with freon
WATER COOLER – Cooling the solvent with water
Condensate drain devices
Automatic start/stop of steam supply to the distiller
DOOR LIGHT – The system of LED illumination of a loading hatch
Nozzle for feeding chemical additives
Automatic impregnation system
A second pump for dosing chemical additives
Self-cleaning air filter
SPRY JET – a high-pressure cleaning system
Stainless steel solvent tanks.
